Запчасти Komatsu PC88MR-8 D- ТОПЛИВН. БАК. С SELF-ПОДАЧА ТОПЛИВН. НАСОС ТОПЛИВН. БАК. AND КОМПОНЕНТЫ

1

22P-04-11310

TANK

|$1

20Y-04-21550

FLOAT ASSEMBLY

2

20Y-04-21560

GUIDE

3

20Y-04-21570

FLOAT

4

20Y-04-21580

CAP

5

07056-18425

STRAINER

6

22P-04-11670

CAP

7

07040-11007

PLUG, DRAIN

8

07002-11023

O-RING

9

22P-04-11121

GAUGE, FUEL LEVEL

10

01010-80610

BOLT

11

01643-30623

WASHER

12

02896-11009

O-RING

13

07000-13050

O-RING

14

02781-00313

UNION

15

07002-11823

O-RING

16

02896-11009

O-RING

17

22P-04-11450

ELBOW

18

07002-11823

O-RING

19

07000-13032

O-RING

20

22B-04-21621

PLATE

21

01010-80616

BOLT

22

01643-30623

WASHER

23

01010-81480

BOLT

24

01643-31445

WASHER, FLAT

|$25

22P-04-11660

COVER ASSEMBLY

25

NSS

COVER

26

22P-04-11480

SEAL, BONDED

27

22P-04-11490

SEAL, BONDED

28

01010-80816

BOLT

29

01643-30823

WASHER
