Запчасти Komatsu PC88MR-8 C- РАДИАТОР, ПОСЛЕОХЛАДИТЕЛЬ И МАСЛООХЛАДИТЕЛЬ СИСТЕМА ОХЛАЖДЕНИЯ

|$0

22P-03-11111

RADIATOR

1

NSS

RADIATOR ASSEMBLY

2

22P-03-11841

SHEET, BONDED

3

22P-03-11851

SHEET, BONDED

4

01010-81025

BOLT

5

01643-31032

WASHER

|$6

22P-03-11121

AFTERCOOLER ASSEMBLY

6

NSS

AFTERCOOLER ASSEMBLY

7

22P-03-11861

SHEET

8

22P-03-11870

SHEET

9

01010-81025

BOLT

10

01643-31032

WASHER

|$12

22P-03-11131

OIL COOLER ASSEMBLY

11

22P-03-11541

OIL COOLER ASSEMBLY

12

22P-03-11551

OIL COOLER ASSEMBLY

13

07000-13035

O-RING

14

22P-03-11181

PLATE

15

01010-81080

BOLT

16

01643-31032

WASHER

17

22P-03-11811

SHEET

18

22P-03-11830

SHEET

19

22P-03-11880

SHEET

20

01010-81025

BOLT

21

01643-31032

WASHER

22

22B-03-12590

CUSHION

23

22P-03-11141

FRAME

24

22P-03-11151

PLATE

25

01010-81025

BOLT

26

01643-31032

WASHER

27

22P-03-11161

SHROUD

28

01010-80820

BOLT

29

01643-30823

WASHER

30

22P-03-11170

PLATE

31

01010-80820

BOLT

32

01643-30823

WASHER

33

22B-03-11350

CAP

34

205-03-62660

PLUG

35

07000-11007

O-RING

36

22P-03-11410

HOSE, L= 150 MM

37

20Y-03-11330

CLIP

38

01164-51030

STUD

39

22P-03-11751

SHEET

40

22P-03-11781

SHEET

41

22P-03-11821

SHEET

42

22P-03-11892

SHEET
