Запчасти Komatsu PC88MR-8 T- ГИДРОЛИНИЯ РУКОЯТЬ ( MM) ЛИНИЯ С ДОПОЛН. АКТУАТОРS РАБОЧЕЕ ОБОРУДОВАНИЕ

1

02765-20410

HOSE, FACE SEAL TYPE

2

21W-973-4630

HOSE, L=1050 MM

3

22P-973-1280

TUBE

4

22P-973-1220

TUBE

5

22B-62-19410

CLAMP

6

01010-81270

BOLT

7

01643-31232

WASHER

8

203-62-43380

CUSHION

9

203-62-43390

CUSHION

10

22P-62-12960

UNION

11

22P-62-12990

NIPPLE

12

22P-973-1120

BRACKET, LH

13

01010-81225

BOLT

14

01643-31232

WASHER

15

22P-973-1130

BRACKET, RH

16

01010-81225

BOLT

17

01643-31232

WASHER

18

02789-10628

PLUG, FACE SEAL TYPE

19

02789-10422

PLUG, FACE SEAL TYPE

20

02896-11012

O-RING

21

02896-11018

O-RING

22

02765-20410

HOSE, FACE SEAL TYPE

23

22P-973-1260

TUBE

24

22B-62-19410

CLAMP

25

01010-81270

BOLT

26

01643-31232

WASHER

27

203-62-43390

CUSHION

28

22P-62-12960

UNION

29

02789-10422

PLUG, FACE SEAL TYPE

30

02896-11012

O-RING

31

02777-202A9

HOSE, FACE SEAL TYPE

32

22P-62-12940

TUBE

33

22P-62-12950

TUBE

34

02896-11008

O-RING

35

02789-10210

PLUG, FACE SEAL TYPE

36

22P-62-13110

BRACKET

37

22P-62-13320

BRACKET

38

20Y-62-K5780

CLAMP

39

01010-81020

BOLT

40

01643-31032

WASHER
