Запчасти Komatsu PC88MR-8 APP- ШАТУН И ПОРШЕНЬ ДВИГАТЕЛЬ

1

6271-31-2110

PISTON, STANDARD

|$1

6271-39-2110

PISTON, OVERSIZE 0.25 MM

|$2

6271-38-2110

PISTON, OVERSIZE 0.50 MM

2

6207-31-2420

PIN, PISTON

3

04065-03012

RING, SNAP

|$5

6271-31-2100

PISTON RING ASSEMBLY, STANDARD

|$6

6271-39-2100

PISTON RING ASSEMBLY, OVERSIZE 0.25 MM

|$7

6271-38-2100

PISTON RING ASSEMBLY, OVERSIZE 0.50 MM

4

NSS

RING, TOP, STANDARD

|$9

NSS

RING, TOP, OVERSIZE 0.25 MM

|$10

NSS

RING, TOP, OVERSIZE 0.50 MM

5

NSS

RING, SECOND, STANDARD

|$12

NSS

RING, SECOND, OVERSIZE 0.25 MM

|$13

NSS

RING, SECOND, OVERSIZE 0.50 MM

6

NSS

RING, OIL, STANDARD

|$15

NSS

RING, OIL, OVERSIZE 0.25 MM

|$16

NSS

RING, OIL, OVERSIZE 0.50 MM

|$17

6207-31-3800

CONNECTING ROD ASSEMBLY

7

NSS

ROD, CONNECTING

8

6207-31-3130

BUSHING

9

6204-31-3310

BOLT

|$21

6208-31-3500

CRANK PIN BEARING ASSEMBLY, STANDARD

|$22

6207-39-3900

CRANK PIN BEARING ASSEMBLY, UNDERSIZE 0.25 MM

|$23

6207-38-3900

CRANK PIN BEARING ASSEMBLY, UNDERSIZE 0.50 MM

|$24

6207-37-3900

CRANK PIN BEARING ASSEMBLY, UNDERSIZE 0.75 MM

|$25

6207-36-3900

CRANK PIN BEARING ASSEMBLY, UNDERSIZE 1.00 MM

10

NSS

BEARING, UPPER, STANDARD

|$27

NSS

BEARING, UPPER, UNDERSIZE 0.25 MM

|$28

NSS

BEARING, UPPER, UNDERSIZE 0.50 MM

|$29

NSS

BEARING, UPPER, UNDERSIZE 0.75 MM

|$30

NSS

BEARING, UPPER, UNDERSIZE 1.00 MM

11

NSS

BEARING, LOWER, STANDARD

|$32

NSS

BEARING, LOWER, UNDERSIZE 0.25 MM

|$33

NSS

BEARING, LOWER, UNDERSIZE 0.50 MM

|$34

NSS

BEARING, LOWER, UNDERSIZE 0.75 MM

|$35

NSS

BEARING, LOWER, UNDERSIZE 1.00 MM
