Запчасти Komatsu PC88MR-8 K-7 ГИДРАВЛИКА КЛАПАН PPCДЛЯ ХОД OPERATOR\XD S ОБСТАНОВКА И СИСТЕМА УПРАВЛЕНИЯ

|$0

702-16-04270

VALVE ASSEMBLY, PILOT

1

NSS

VALVE BODY

2

NSS

VALVE

3

702-16-51140

SHIM, T=0.30 MM

4

702-16-53420

SPRING

5

702-16-53140

RETAINER

6

702-16-54420

SPRING

7

702-16-53170

PISTON

8

702-16-71150

SEAL

9

702-16-71160

SEAT

10

702-16-73630

CASE

11

NSS

LEVER

12

NSS

SHAFT

13

NSS

PLATE

14

01010-80855

BOLT

15

01643-30823

WASHER

16

01010-80816

BOLT

17

702-16-54331

WASHER, T=1.60 MM

|$18

702-16-54341

WASHER, T=1.30 MM

|$19

702-16-54351

WASHER, T=1.00 MM

|$20

702-16-56380

WASHER, T=1.90 MM

|$21

702-16-56390

WASHER, T=2.20 MM

18

04025-00432

PIN, SPRING

19

702-16-54430

BUSHING

20

07000-12018

O-RING

21

702-16-73610

DAMPER ASSEMBLY

22

01023-10306

SCREW

23

702-16-73650

PIN

24

04022-04016

PIN, DOWEL

25

NSS

PLUG

26

NSS

PLUG

27

07040-11209

PLUG

28

07002-11223

O-RING

29

700-84-11730

BALL

30

702-16-55940

PLUG

31

702-16-55950

SEAT
