/ / / / / / K- OPERATOR КАБИНА ПЕРЕДН. ОКНА
Запчасти Komatsu PC88MR-8 K- OPERATOR КАБИНА ПЕРЕДН. ОКНА OPERATOR\XD S ОБСТАНОВКА И СИСТЕМА УПРАВЛЕНИЯ
35
36
41
42
44
43
42
28
37
40
30
29
44
39
43
32
38
33
34
45
31
17
34
36
35
19
20
21
18
9
11
8
12
13
6
10
5
14
12
15
11
7
13
15
16
3
13
1
2
25
13
27
26
22
4
23
24
|$1
22P-53-00081
WINDOW ASSEMBLY, FRONT
1
NSS
FRAME, FRONT WINDOW
2
22P-53-18320
GLASS, FRONT WINDOW
3
22P-53-18380
SEAL
4
22P-53-18371
SEAL
5
22B-54-15411
LOCK ASSEMBLY
6
22B-54-15440
CASE
7
22B-54-15470
KNOB
8
22B-54-15421
LOCK ASSEMBLY
9
22B-54-15450
CASE
10
22B-54-15480
KNOB
11
01010-D0816
BOLT
12
208-53-11330
WASHER
13
22B-54-28591
ROLLER
14
22B-54-15560
STOPPER
15
01580-11008
NUT
16
20Y-54-65540
CAP
17
22P-53-18511
PLATE
18
01435-41020
BOLT
19
01240-00616
SCREW
20
22P-53-18521
BRACKET
21
01435-00616
BOLT
22
22P-53-18531
BLOCK
23
01252-80616
BOLT, SOCKET HEAD
24
01641-50608
WASHER, FLAT
25
20Y-54-52192
BLOCK
26
01252-80616
BOLT, SOCKET HEAD
27
01641-50608
WASHER, FLAT
28
22B-54-15682
BLOCK
29
01252-80625
BOLT, SOCKET HEAD
30
01643-70623
WASHER, FLAT
31
22B-54-28440
STOPPER
32
01252-80616
BOLT, SOCKET HEAD
33
01643-70623
WASHER, FLAT
34
20Y-54-51621
STRIKER
35
20T-54-74550
NUT
36
01643-71032
WASHER, FLAT
37
21J-06-12440
SWITCH, WIPER LIMIT
38
01583-01811
NUT
39
01640-21826
WASHER, FLAT
40
22P-53-18481
BRACKET
41
22P-53-18491
BRACKET
42
01435-40616
BOLT
43
20Y-54-11611
STOPPER
44
01580-11008
NUT
45
22B-54-28350
TRIM
