Запчасти Komatsu PC88MR-8 H8-9 ГИДРОЛИНИЯ ПРОПОРЦИОНАЛЬН. PRESSURE УПРАВЛ-Е (PPC) КЛАПАН КОНТУР КРЕПЛЕНИЕ ГИДРАВЛИКА

1

22P-62-12250

VALVE ASSEMBLY

2

22L-62-24851

VALVE ASSEMBLY

3

20U-Y14-1550

ELBOW, ORANGE-YELLOW

4

22P-62-13350

ADAPTER

5

07000-12014

O-RING

6

02782-10210

ELBOW

7

07002-11423

O-RING

8

22M-62-15590

JOINT

9

02896-11008

O-RING

10

22P-62-13350

ADAPTER

11

22P-62-13360

ELBOW, BLACK-YELLOW

12

07000-12014

O-RING

13

07002-11423

O-RING

14

21W-62-42940

NIPPLE

15

201-62-75420

ELBOW, GREEN-ORANGE

16

07002-11423

O-RING

17

21U-62-34710

BAND, YELLOW

18

21U-62-34720

BAND, BLACK

19

21U-62-34730

BAND, GREEN

20

21U-62-34740

BAND, ORANGE

21

01010-81025

BOLT

22

01643-31032

WASHER

23

22P-62-13660

BRACKET

24

01010-81225

BOLT

25

01643-31232

WASHER

26

22P-62-13670

BRACKET

27

01010-81020

BOLT

28

01643-31032

WASHER

29

08034-20536

BAND

30

22L-98-22910

WRENCH

31

22P-00-11510

PLATE

32

22P-00-11520

PLATE

33

09822-00020

CASE

34

09822-03010

DECAL, WARNING, LEVER SHIFT PATTERN

35

22M-98-11181

DECAL, WARNING, LOCK LEVERS

36

22B-00-21410

PLATE

37

22J-98-1A610

DECAL, 2-WAY SELECT VALVE
