Запчасти Komatsu PC88MR-8 H8-9 ГИДРОЛИНИЯ PPC ОСНОВН. КЛАПАН КОНТУР (/) ГИДРАВЛИКА
№
Артикул
Название
Примечание
Количество
|$0
22P-62-11621
HOSE ASSEMBLY
1
22P-62-11680
HOSE, L=2400 MM
2
22P-62-11711
HOSE, L=2460 MM
N/I
21U-62-34710
BAND, YELLOW
N/I
21U-62-34740
BAND, ORANGE
N/I
21U-62-34760
BAND, RED
|$6
22P-62-11631
HOSE ASSEMBLY
3
22P-62-11440
HOSE, L=2340 MM
4
20U-62-22190
O-RING
5
22P-62-11641
HOSE, L=2130 MM
6
22P-62-11650
HOSE, L=2400 MM
7
22P-62-11671
HOSE, L=2380 MM
N/I
21U-62-34710
BAND, YELLOW
N/I
21U-62-34720
BAND, BLACK
N/I
21U-62-34730
BAND, GREEN
N/I
21U-62-34740
BAND, ORANGE
N/I
21U-62-34750
BAND, BLUE
N/I
21U-62-34770
BAND, WHITE
N/I
21U-62-34780
BAND, BROWN
|$19
21W-60-43200
VALVE ASSEMBLY
8
21W-62-43930
NIPPLE
9
21W-62-44750
BODY
10
21W-62-42940
NIPPLE
11
07002-11423
O-RING
12
02896-11008
O-RING
|$25
22P-62-11871
HOSE ASSEMBLY
13
22P-62-11761
HOSE, L=2240 MM
14
21W-62-41521
HOSE, L=2200 MM
15
22P-62-11780
HOSE, L=2300 MM
16
21W-62-51140
HOSE, L=1970 MM
N/I
21U-62-34720
BAND, BLACK
N/I
21U-62-34730
BAND, GREEN
N/I
21U-62-34750
BAND, BLUE
|$33
22P-62-11881
HOSE ASSEMBLY
17
22P-62-11451
HOSE, L=2050 MM
18
20U-62-22190
O-RING
19
22P-62-11721
HOSE, L=1740 MM
20
22P-62-11731
HOSE, L=2030 MM
21
22P-62-11741
HOSE, L=2180 MM
22
22P-62-11751
HOSE, L=2160 MM
|$40
21W-60-43200
VALVE ASSEMBLY
23
21W-62-43930
NIPPLE
24
21W-62-44750
BODY
25
21W-62-42940
NIPPLE
26
07002-11423
O-RING
N/I
21U-62-34710
BAND, YELLOW
N/I
21U-62-34720
BAND, BLACK
N/I
21U-62-34760
BAND, RED
N/I
21U-62-34770
BAND, WHITE
N/I
21U-62-34780
BAND, BROWN
27
02896-11008
O-RING
|$51
22P-62-11801
HOSE ASSEMBLY
28
22P-62-11791
HOSE, L=2150 MM
29
22P-62-11851
HOSE, L=1150 MM
N/I
21U-62-34710
BAND, YELLOW
N/I
21U-62-34730
BAND, GREEN
N/I
21U-62-34760
BAND, RED
30
02761-00204
HOSE, FACE SEAL TYPE
