Запчасти Komatsu PC88MR-8 H- ГИДРОЛИНИЯ РУКОЯТЬ И КОВШ КОНТУР ГИДРАВЛИКА

1

02781-00425

UNION

2

07002-12434

O-RING

3

02896-11012

O-RING

4

21W-62-42481

NIPPLE

5

07002-12434

O-RING

6

02896-11015

O-RING

7

02781-00422

UNION

8

07002-12034

O-RING

9

02896-11012

O-RING

10

22P-62-11141

HOSE, L=3630 MM

|$10

21U-62-34740

BAND, ORANGE

11

22P-62-11151

HOSE, L=3660 MM

|$12

21U-62-34730

BAND, GREEN

12

22P-62-11161

HOSE, L=3630 MM

|$14

21U-62-34760

BAND, RED

13

22P-62-11171

HOSE, L=3690 MM

|$16

21U-62-34750

BAND, BLUE

14

21W-62-42411

NIPPLE

15

07002-11823

O-RING

16

02896-11009

O-RING

17

22P-62-11271

HOSE

|$21

21U-62-34720

BAND, BLACK

|$22

21U-62-34770

BAND, WHITE

18

22P-62-11281

HOSE, L=1890 MM

|$24

21U-62-34760

BAND, RED

|$25

21U-62-34770

BAND, WHITE

19

22P-62-12661

BRACKET

20

22P-62-13540

CLAMP

21

07095-00316

CUSHION

22

01010-81265

BOLT

23

01643-31232

WASHER

24

01010-81240

BOLT

25

01643-31232

WASHER

26

22P-62-13510

CLAMP

27

07095-00316

CUSHION

28

01010-81255

BOLT

29

01643-31232

WASHER
