Запчасти Komatsu PC88MR-8 H-8 ГИДРОЛИНИЯ ПОДАЮЩ. КОНТУР - ДЛЯ ТОПЛИВН. SELF-ПОДКАЧИВАЮЩ. НАСОС И АКТУАТОРS ГИДРАВЛИКА

1

02782-10628

ELBOW

2

21W-62-43510

HOSE, L=590 MM

3

02781-00628

UNION

4

07002-12434

O-RING

5

02896-11018

O-RING

6

02782-10630

ELBOW

7

21W-62-43521

HOSE, L=490 MM

8

02781-00628

UNION

9

07002-12434

O-RING

10

02896-11018

O-RING

11

02781-0021D

UNION

12

02766-00208

HOSE, FACE SEAL TYPE, L=800 MM

13

22P-62-13510

CLAMP

14

07095-00314

CUSHION

15

01010-81260

BOLT

16

01643-31232

WASHER

17

02782-10212

ELBOW

18

11Y-62-12490

UNION

19

07002-11423

O-RING

20

02896-11008

O-RING

21

22P-62-13800

ELBOW ASSEMBLY

22

21W-62-44920

BLEEDER

23

07040-11007

PLUG

24

07002-11023

O-RING

25

21W-62-43551

HOSE, L=540 MM

26

21W-62-43950

ELBOW ASSEMBLY

27

203-62-58880

ADAPTER

28

07002-11423

O-RING

29

02896-11009

O-RING

30

21W-62-43160

BLOCK

31

07000-13030

O-RING

32

01010-80835

BOLT

33

01643-30823

WASHER

34

02781-00422

UNION

35

07002-12034

O-RING

36

21W-62-43531

HOSE, L=480 MM

37

21W-62-42970

TEE

38

07002-12434

O-RING

39

02896-11012

O-RING

40

07040-11007

PLUG

41

07002-11023

O-RING
