Запчасти Komatsu PC88MR-8 H- ОСНОВН. ПОРШЕНЬ НАСОС ВНУТР. ЧАСТИ (/) ГИДРАВЛИКА

|$2

708-3T-04210

BLOCK ASSEMBLY

1

NSS

CYLINDER BLOCK

2

NSS

PLATE, VALVE

3

708-1W-23130

SEAT

4

708-3T-13150

SPRING

5

04065-04218

RING, SNAP (FOR HOLE SIDE)

6

708-3T-13351

GUIDE, RETAINER

7

708-3T-13360

PIN

8

708-3T-13340

RETAINER, SHOE

9

708-3T-13312

PISTON SUBASSEMBLY

|$12

708-3T-04220

FLANGE ASSEMBLY

10

NSS

FLANGE

11

NSS

PLUG

12

708-3T-13421

BALL

13

708-3T-13412

CAM, ROCKER

14

708-3T-13451

STUD

15

04020-01024

PIN, DOWEL

16

01252-61235

BOLT, HEXAGON SOCKET HEAD

17

07000-B2012

O-RING

18

708-7T-51210

O-RING

19

708-3T-14222

PLUG

20

07000-12010

O-RING

21

01643-51232

WASHER, FLAT

22

01582-11210

NUT

23

708-3T-14114

PISTON SUBASSEMBLY .

24

708-3T-14120

SPRING
