Запчасти Komatsu PC88MR-8 ОСНОВН. КОНСТРУКЦИЯ, БЛОК КОНДИЦИОНЕРА (№8-) ОСНОВН. КОНСТРУКЦИЯ, С БЫСТРОСЪЕМН. МЕХ-М ТРУБЫ, AM-FM РАДИО, ASIA И OCEANIA

|$0

22B-979-2701

Air Conditioner Assembly

1

ND245450-6630

Case

2

ND245450-6640

Case

3

ND245450-6650

Case

4

ND116576-8040

Plate

4

ND446010-4660

Evaporator Assembly

5

ND446600-1472

Evaporator

6

ND949142-0020

O-ring

7

ND949142-0030

O-ring

8

ND446250-5990

Tube

9

ND447500-2980

Valve

9

ND447500-2660

Valve

10

ND949046-3100

Bolt

11

ND146687-2091

Packing

12

ND146687-2080

Packing

13

ND146687-6350

Packing

14

ND146657-8850

Packing

15

ND949046-3610

Bolt

16

ND445021-3941

Plug

17

ND116420-6830

Heater

18

ND116340-8820

Motor Assembly

19

ND949008-0330

Screw, Tapping

20

ND077800-1040

Transistor

21

ND077500-5890

Thermistor Assembly

22

ND246790-2060

Clamp

23

ND077500-0650

Thermistor

24

ND017661-3700

Clamp

25

ND063600-4580

Servo Motor Assembly

26

ND063800-0300

Servo Motor Assembly

27

ND116660-0600

Door

28

ND116640-8051

Dumper

29

ND116650-9870

Door

30

ND017231-1400

Clamp

31

ND116682-0670

Lever

32

ND116662-8420

Shaft

33

ND017212-1720

Lock

34

ND949001-1730

Screw, Tapping

35

ND146687-6360

Packing

36

ND146687-6370

Packing

37

ND146687-6380

Packing

38

ND145530-1210

Filter, Recirculation Air

39

ND949008-0460

Screw, Tapping

40

ND116576-8050

Plate

41

ND116576-8060

Plate

42

ND116780-4690

Lever

43

ND116780-4700

Lever

44

ND116780-4710

Lever

45

ND116682-7310

Lever

46

ND116782-1370

Lever

47

ND116662-8430

Shaft

48

ND116662-8440

Shaft

49

ND246470-5631

Wiring Harness

50

ND246780-1370

Clamp

51

ND146687-6400

Packing

52

ND017780-3110

Cable
