Запчасти Komatsu PC88MR-8 ОСНОВН. КОНСТРУКЦИЯ, КОНСОЛЬН. БЛОК, ЛЕВ. (№-) ОСНОВН. КОНСТРУКЦИЯ, С AM-FM РАДИО, СЕВ. АМЕРИКА

1

01010-80820

Bolt

2

01643-30823

Washer

3

20Y-62-18910

Plug

4

07000-12018

O-ring

5

20Y-62-18890

Bolt, Joint

6

07000-12015

O-ring

7

02781-0021D

Union

8

07002-11423

O-ring

9

02896-11008

O-ring

10

22B-43-23112

Frame

11

01010-D1030

Bolt

12

01643-71032

Washer

13

06124-01616

Bearing

14

22B-43-23722

Bracket

14

22B-43-23721

Bracket

15

22B-43-23161

Shaft

16

01435-00612

Bolt

17

22B-43-23471

Spring

18

04050-12015

Pin, Cotter

19

01640-20816

Washer

20

426-925-3981

Washer

21

22B-43-23143

Guide

21

22B-43-23142

Guide

22

04205-30835

Pin

23

21U-43-32430

Collar

24

04050-12015

Pin, Cotter

25

01640-20816

Washer

26

21U-43-32380

Spring, Gas

27

04050-12015

Pin, Cotter

28

04050-13015

Pin, Cotter

29

01640-20816

Washer

30

22B-06-21420

Switch, Work Equipment Lock

31

22U-06-22490

Plate

32

01023-60320

Screw

33

08059-00310

Clip

34

20Y-54-11611

Stopper

35

01580-11008

Nut

36

208-06-19170

Clip

37

04434-51710

Clip

38

01010-81025

Bolt

39

01643-31032

Washer

40

22B-43-23213

Cover

41

01010-80616

Bolt

42

01643-30623

Washer

43

20Y-43-41290

Collar

44

22B-43-23221

Cover

45

01245-00616

Screw

46

01643-70623

Washer

47

01010-80616

Bolt

48

01643-30623

Washer

49

01435-00616

Bolt

50

20Y-43-41290

Collar

51

22B-43-23231

Cover

52

01245-00616

Screw

53

01643-70623

Washer

54

20Y-43-41290

Collar

55

22B-43-23271

Cover

56

08059-00515

Clip

57

22B-43-23280

Seal
