Запчасти Komatsu PC88MR-8 МЕХАНИЗМ ПОВОРОТА И МОТОР, МОТОР ПОВОРОТА (/) (№-) МЕХАНИЗМ ПОВОРОТА И МОТОР

|$0

22P-26-11000

Swing Machinery Assembly

|$1

708-7S-00270

Motor Assembly

|$2

708-7S-01260

Motor Subassembly

1

708-7S-21130

Plate, Swash

2

708-7S-21511

Housing

3

706-73-71450

Plug

4

07002-61423

O-ring

5

709-25-11650

Valve, Check

6

700-80-63230

Spring

7

708-7S-21610

Plug

8

07002-62434

O-ring

|$11

706-73-72710

Valve Subassembly

9

Valve

10

Poppet

11

Plug

12

706-73-72440

Spring

13

708-7S-21620

Plug

14

07002-62434

O-ring

15

07000-B2145

O-ring

16

720-68-19610

Pin

17

01252-61245

Bolt, Hexagon Socket Head

18

708-7S-22110

Shaft

19

708-7S-22140

Bearing

20

708-7S-22150

Bearing

21

708-7T-12330

Seal, Oil

22

708-7S-22310

Cover

23

07000-B2055

O-ring

24

04065-06020

Ring, Snap

25

708-7S-23111

Cylinder Block

26

708-7S-23210

Plate

27

720-68-19610

Pin

28

708-2L-23360

Pin

29

708-7S-13530

Spacer

30

708-7S-23510

Spring

31

04065-03212

Ring, Snap

32

708-1S-13350

Retainer, Guide

33

708-1S-13340

Retainer

34

708-7S-23310

Piston Subassembly

35

708-7S-23410

Plate

36

708-7S-25130

Plate

37

708-7S-25120

Disc

38

708-7S-25140

Piston, Brake

39

07000-B2130

O-ring

40

07000-B2120

O-ring

41

708-7S-25150

Spring
