Запчасти Komatsu PC88MR-6 2-СЕКЦИОНН. СТРЕЛА РАБОЧЕЕ ОБОРУДОВАНИЕ

\0

707-01-0R030

2nd BOOM CYLINDER, ASSY.

1

707-58-80800

PISTON ROD

2

707-76-80470

BUSHING

3

07179-13094

RING, BACK-UP

4

707-29-14380

CYLINDER HEAD

5

01010-81875

BOLT

6

707-41-11840

WASHER

7

707-52-90560

BUSHING

8

707-44-14910

GASKET

9

707-36-14760

PISTON

10

01310-01216

DOWEL

11

707-13-14850

CYLINDER

\11

707-99-54160

KIT, GASKET

12

07145-00080

SEAL, DUST

13

195-63-92190

GASKET

14

707-51-80030

GASKET

15

707-51-80640

GASKET

16

707-35-91420

RING, BACK-UP

17

07000-15130

O-RING

18

707-39-14110

SEAL

19

707-35-90940

RING, BACK-UP

20

07000-15080

O-RING

21

707-44-14180

GASKET

22

21W-09-R2680

TUBE

23

02896-11015

O-RING

24

02892-03018

O-RING

25

01252-70825

BOLT, HEXAGON SOCKET HEAD

26

21D-09-73690

WASHER

27

226-61-11110

FLANGE

28

21D-09-69870

O-RING

29

02896-11015

O-RING

30

01252-70830

BOLT, HEXAGON SOCKET HEAD

31

22E-62-11570

CLAMP

32

07281-01919

CLAMP
