Запчасти Komatsu PC88MR-6 ПОРШЕНЬ ДВИГАТЕЛЬ

Схема запчастей Komatsu PC88MR-6 - ПОРШЕНЬ ДВИГАТЕЛЬ
4
5
6
3
2
3
1
9
7
13
12
11
8
10

Артикул

Название

Примечание

Количество

\0

6205-G0-RA10

MOTOR, ASSEMBLY

1

6205-31-2190

PISTON, STANDARD

1

6205-39-2190

PISTON, OVERSIZE 0.25MM

1

6205-38-2190

PISTON, OVERSIZE 0.50MM

2

6204-31-2410

PIN, PISTON

3

04065-03012

RING, SNAP

3

6205-31-2300

PISTON RING ASSEMBLY, STANDARD

3

6205-39-2300

PISTON RING ASSEMBLY, OVERSIZE 0.25MM

\3

6205-38-2300

PISTON RING ASSEMBLY, OVERSIZE 0.50MM

4

RING, STOP

5

RING, SECOND

6

RING, OIL

\6

6204-31-3101

CONNECTING ROD, ASSEMBLY

7

ROD, CONNECTING

8

CAP

9

6204-31-3130

BUSHING

10

6204-31-3310

BOLT

11

6207-31-3140

PIN

\11

6204-31-3400

CRANK PIN, METAL ASSEMBLY, STANDARD

\11

6207-39-3300

CRANK PIN, METAL ASSEMBLY, UNDERSIZE 0.25MM

\11

6207-38-3300

CRANK PIN, METAL ASSEMBLY, UNDERSIZE 0.50MM

\11

6207-37-3300

CRANK PIN, METAL ASSEMBLY, UNDERSIZE 0.75MM

\11

6207-36-3300

CRANK PIN, METAL ASSEMBLY, UNDERSIZE 1.00MM

12

METAL

13

METAL

Выбрано товаров: 25
