Запчасти Komatsu PC88MR-6 ГИДР. НАСОС. (/) РАБОЧЕЕ ОБОРУДОВАНИЕ ГИДРАВЛИКА

\0

708-3T-00230

HYDRAULIC PUMP, ASSEMBLY

\0

708-3T-03240

VALVE ASSEMBLY

\0

708-3T-04310

BODY, ASSEMBLY

1

BODY

2

PLUG

\2

708-3T-04320

PISTON, SUBASSEMBLY

3

PISTON

4

SLEEVE

5

708-1S-15390

SEAL

\5

708-3T-04331

PISTON, SUBASSEMBLY

6

PISTON

7

PLUG

8

708-1S-15390

SEAL

9

07002-11623

O-RING

10

708-3T-15280

SPOOL

11

708-3T-15310

SEAT

12

708-3T-15330

SPRING

13

708-3T-15290

RETAINER

14

708-3T-15250

PLUG

15

07000-11006

O-RING

16

01583-11207

NUT

17

708-3T-15260

LEVER

18

708-1S-15280

SPACER

19

07002-11623

O-RING

20

708-1S-15290

PLUG

21

708-3T-15510

PLUG

22

07002-11223

O-RING

23

708-3T-15541

SPOOL

24

708-3T-15521

PLUG

25

07000-11008

O-RING

26

07001-01008

RING, BACK-UP

27

01583-51408

NUT

28

708-3T-15530

SPRING

29

708-1S-15350

SEAT

30

708-1S-15360

SEAT

31

708-3T-15811

ORIFICE

32

702-21-55901

PILOT VALVE

33

01252-60635

BOLT

34

708-8E-16150

PLUG

35

07002-11023

O-RING

36

20B-27-11210

BLEEDER
