Запчасти Komatsu PC850SE-8 BM ЦИЛИНДР ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

707-01-XP200

CYLINDER GROUP,L.H. (FINAL COATING)

G-2

707-01-XP210

CYLINDER GROUP,R.H. (FINAL COATING)

|$5

707-01-0K200

CYLINDER ASS'Y

1

707-13-20480

CYLINDER

2

707-46-13010

BUSHING

3

07043-00108

PLUG

4

707-27-20910

HEAD,CYLINDER

5

707-51-14080

PACKING,ROD (KIT)

6

707-51-14650

RING,BUFFER (KIT)

7

707-52-91170

BUSHING

8

707-75-14110

RING,SNAP

9

198-63-93170

SEAL,DUST (KIT)

10

07179-14160

RING,SNAP

11

07000-15195

O-RING (KIT)

12

07001-05195

RING,BACK-UP (KIT)

13

07000-15195

O-RING (KIT)

14

07001-05195

RING,BACK-UP (KIT)

15

721-71-32010

COLLAR

16

01011-82705

BOLT

17

01643-32780

WASHER

18

209-63-53320

ROD,PISTON

19

707-46-11520

BUSHING

20

07043-00108

PLUG

21

707-36-20430

PISTON

22

07000-B5130

O-RING (KIT)

23

07001-05130

RING,BACK-UP (KIT)

24

707-44-20910

RING

25

707-39-20020

RING,WEAR (KIT)

26

707-44-20190

RING,PISTON (KIT)

27

01310-01232

SCREW

28

707-71-61510

PLUNGER

29

707-86-13450

TUBE,L.H.

29

707-86-13460

TUBE,R.H.

30

707-86-11650

TUBE,L.H.

30

707-86-11670

TUBE,R.H.

31

07000-13038

O-RING (KIT)

32

01010-81245

BOLT

33

01643-31232

WASHER

34

07378-11210

HEAD

35

07371-51260

FLANGE

36

01010-81245

BOLT

37

01643-31232

WASHER

38

707-88-26130

BAND

39

707-88-28390

BRACKET

40

07372-21240

BOLT

41

01643-51232

WASHER

42

07283-33442

CLIP

43

01597-01009

NUT

44

01643-31032

WASHER

|$53

707-99-76230

SERVICE KIT
