Запчасти Komatsu PC850SE-8 ОСНОВН. КЛАПАН (5-СЕКЦИОНН.) (/)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$1

709-15-94200

CONTROL VALVE

|$$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.Y1665-01A0 T0 Y1665-05A0.

1

709-90-71600

VALVE ASS'Y,SUCTION AND SAFETY

2

07002-03634

O-RING

3

709-90-71100

VALVE ASS'Y,SUCTION

4

07002-03634

O-RING

5

723-60-23800

VALVE ASS'Y,SUCTION

6

07002-13634

O-RING

|$9

709-10-92400

ORIFICE ASS'Y

7

709-10-91370

ORIFICE

8

709-14-11660

ORIFICE

9

700-93-11320

O-RING

10

07002-13634

O-RING

11

07000-11007

O-RING

12

709-14-12450

BLOCK

13

07000-12010

O-RING

14

07000-12012

O-RING

15

709-14-12460

PLUG

16

708-8E-16160

PLUG

17

07002-11023

O-RING

18

01643-30623

WASHER

19

01580-10605

NUT

20

709-14-12470

PLUG

21

07002-11423

O-RING

22

709-14-12490

PLATE

23

01643-31032

WASHER

24

01010-81016

BOLT

25

08193-20010

CLIP

26

01010-81045

BOLT

27

6112-21-6960

SPACER

28

04434-50810

CLIP

29

01643-31032

WASHER

30

729-13-01110

SENSOR ASS'Y

31

01252-60835

BOLT
