Запчасти Komatsu PC850SE-8 МОТОР ПОВОРОТА (/)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$1

706-7G-01030

MOTOR ASS'Y

|$$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.Y1640-01A0 TO Y1640-03A0.

|$3

706-7G-03030

MOTOR SUB ASS'Y

1

706-7G-41610

SHAFT,DRIVE

2

706-75-42880

BEARING

3

706-75-43810

SPACER

4

706-7E-11260

SPRING

5

706-7E-11270

SEAT

6

706-76-40890

BEARING

7

706-75-05040

SPACER KIT

7

SPACER, 3.1MM

7

SPACER, 3.4MM

7

SPACER, 3.7MM

8

04064-04518

RING,SNAP

9

706-7E-11280

SEAL,OIL

10

706-75-43720

SPACER

11

04065-06220

RING

12

706-7G-41210

BLOCK,CYLINDER

13

706-7G-41710

PLATE,VALVE

14

706-75-43750

PIN,DOWEL

15

706-7G-41120

SHAFT,CENTER

16

706-7G-41130

RING,CENTER

17

706-7G-41140

SPRING

|$24

706-7G-05010

RETAINER KIT

18

RETAINER

19

SCREW

20

706-7G-41160

PISTON SUB ASS'Y

21

706-7G-91340

PLATE

22

706-7G-91350

DISC

23

706-7G-91110

PISTON,BRAKE

24

706-77-40370

O-RING

25

708-8F-31610

O-RING

26

706-7G-91360

SPRING
