Запчасти Komatsu PC850SE-8 ОСНОВН. НАСОС (/)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

Схема запчастей Komatsu PC850SE-8 - ОСНОВН. НАСОС (/)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ
1
2
3
3
4
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
31
32
33
34
35
36
36
37
37
38
38
39
39

Артикул

Название

Примечание

Количество

|$1

708-2K-00110

PUMP ASS'Y

|$$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.Y1600-01A0 T0 Y1600-14A0.

|$3

708-1W-00900

PUMP ASS'Y

|$4

708-1W-00910

PUMP ASS'Y

|$5

708-1W-01910

PUMP SUB ASS'Y

|$6

708-1W-04440

CASE ASS'Y

1

CASE,PUMP

2

PLUG

3

708-8E-16160

PLUG

4

07002-11023

O-RING

5

07040-11409

PLUG

6

07002-11423

O-RING

7

706-73-42370

O-RING

8

07000-B1009

O-RING

9

04020-01024

PIN

10

01010-61470

BOLT

11

01643-31445

WASHER

12

708-1W-41540

CAP,END

13

708-1W-42120

BEARING

14

708-3T-13420

BALL

15

708-1W-43420

CAM,ROCKER

16

04260-01270

BALL

17

708-1U-12120

SHAFT

18

708-1W-42110

BEARING

19

708-1U-12320

CASE

20

708-1W-42130

SEAL

21

07000-B2065

O-RING

22

708-1W-05810

SPACER KIT

22

708-1W-42310

SPACER, 1.6MM

22

708-1W-42320

SPACER, 1.7MM

22

708-1W-42330

SPACER, 1.8MM

22

708-1W-42340

SPACER, 1.9MM

22

708-1W-42350

SPACER, 2.0MM

22

708-1W-42360

SPACER, 2.1MM

22

708-1W-42370

SPACER, 2.2MM

23

04065-07225

RING

24

BLOCK,CYLINDER

25

PLATE,VALVE

26

720-68-19610

PIN

27

708-1W-43130

SEAT

28

708-1W-43140

SPRING

29

04065-04818

RING

30

708-1W-43350

GUIDE,RETAINER

31

708-3T-13360

PIN

32

708-1W-43341

RETAINER,SHOE

33

708-1U-13310

PISTON SUB ASS'Y

34

708-1W-44110

PISTON SUB ASS'Y

35

708-3T-14120

SPRING

36

708-1U-14221

SCREW

37

07000-12011

O-RING

38

01643-31232

WASHER

39

01582-11210

NUT

Выбрано товаров: 52
