Запчасти Komatsu PC850SE-8 ОСНОВН. НАСОС (/)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$1

708-2K-00110

PUMP ASS'Y

|$$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.Y1600-01A0 T0 Y1600-14A0.

|$3

708-2K-01110

PUMP SUB ASS'Y

|$4

708-2K-04260

CRADLE ASS'Y

1

CRADLE

2

CAM,ROCKER

3

708-2K-13430

PLATE

4

04020-01638

PIN,DOWEL

5

708-2K-11170

O-RING

6

01252-61445

BOLT

7

708-2K-14110

PISTON

8

708-2K-14130

ROD

|$13

708-2K-03220

CAM ASS'Y

9

BRACKET

10

PIN

11

CAM

12

BOLT

13

720-68-19610

PIN

14

01252-61030

BOLT

15

708-2K-14250

SCREW

16

07000-B3039

O-RING

17

07001-03039

RING

18

01643-33080

WASHER

19

01583-13018

NUT

20

708-2K-14230

SCREW

21

07000-B3032

O-RING

22

07001-03032

RING

23

01643-33080

WASHER

24

01583-13018

NUT
