Запчасти Komatsu PC850SE-8 ОСНОВН. НАСОС (/)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$1

708-2K-00110

PUMP ASS'Y

|$$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.Y1600-01A0 T0 Y1600-14A0.

|$3

708-2K-01110

PUMP SUB ASS'Y

1

708-2K-12160

SHAFT,FRONT

2

708-2K-12260

BEARING

3

708-2K-05050

WASHER KIT

3

708-2K-12170

WASHER, 5.0MM

3

708-2K-12180

WASHER, 5.1MM

3

708-2K-12190

WASHER, 5.2MM

3

708-2K-12380

WASHER, 4.8MM

3

708-2K-12390

WASHER, 4.9MM

4

04064-09030

RING,RING

5

708-2K-12230

SEAL,OIL

6

708-2K-12310

PLATE

7

07000-A2130

O-RING

8

01252-60820

BOLT

|$17

708-2K-04271

CYLINDER BLOCK ASS'Y,FRONT

9

CYLINDER BLOCK

10

VALVE,PLATE

11

708-18-13230

PIN

12

708-2K-13361

PIN

13

708-2K-13130

SEAT

14

708-2K-13151

SPRING

15

708-2K-13140

SEAT

16

04065-08530

RING

17

708-2K-13350

GUIDE,RETAINER

18

708-2K-13371

RETAINER,SHOE

19

708-2K-13312

PISTON SUB ASS'Y
