Запчасти Komatsu PC850-8E0 ПОВОРОТНОЕ СОЕДИНЕНИЕ, СОЕДИНИТЕЛЬН. ЧАСТИ (№-) ПОВОРОТНОЕ СОЕДИНЕНИЕ

1

209-64-17250

Tee

2

07002-62434

O-ring

3

02896-61015

O-ring

4

209-62-57221

Elbow

5

07002-62434

O-ring

6

07371-31049

Flange, Split

7

07372-21035

Bolt

8

01643-51032

Washer

9

07040-11812

Plug

10

20U-62-41610

Elbow

11

07002-61823

O-ring

12

02896-61012

O-ring

13

01010-61440

Bolt

14

01643-31445

Washer, Flat

15

209-64-11880

Plate

16

209-62-52560

Pin

17

01640-21626

Washer, Flat

18

04052-11664

Pin, Snap

19

01640-22032

Washer

20

04050-15030

Pin, Cotter

21

07371-31049

Flange, Split

22

07372-21035

Bolt

23

01643-51032

Washer

24

07371-31049

Flange, Split

25

07372-21035

Bolt

26

01643-51032

Washer

27

02781-00315

Union

28

07002-12034

O-ring

29

02896-11009

O-ring

30

20U-62-46570

Elbow

31

07002-62434

O-ring

32

02896-61015

O-ring

33

21W-62-42690

Elbow

34

07002-62034

O-ring

35

02896-61015

O-ring

36

02783-10315

Elbow

37

07002-12034

O-ring

38

02896-11009

O-ring

39

07125-01419

Hose, Flange Type

|$39

07125-01418

Hose, Flange Type

40

02762-00506

Hose

41

209-64-45850

Hose

42

07098-010A6

Hose, Flange Type

43

07098-01008

Hose, Flange Type

44

02761-00314

Hose, Face Seal Type

45

07098-010A8

Hose, Flange Type

46

07098-01010

Hose, Flange Type
