Запчасти Komatsu PC850-8E0 ГИДР. БАК., БАК (№-) ГИДР. БАК., ЗАПЫЛЕНН МЕСТН. ARRANGEMENT

1

209-60-77120

Cover

2

07000-15230

O-ring

3

209-60-77330

Cover

4

09455-12013

Hinge,Welded

5

209-04-51330

Seal

6

205-60-71220

Lock Assembly

7

01010-81230

Bolt

8

01643-31232

Washer

8

209-60-77171

Strainer Assembly

9

209-60-77131

Rod

10

12R-60-11230

Spring

11

20Y-60-21320

Holder

12

209-60-51120

Strainer

13

21N-09-11140

O-ring

14

17A-60-11310

Cap Assembly

15

20Y-60-21470

Element

16

208-60-71181

Filler Neck

16

208-60-71180

Filler Neck

17

20Y-60-21340

Gasket

18

01252-A0516

Bolt, Hexagon Socket Head

19

01601-20513

Washer

20

07056-10045

Strainer

21

04065-04718

Ring, Snap

22

07261-21419

Hose

23

07285-00220

Clip

24

04434-52312

Clip

25

01010-81225

Bolt

26

01643-31232

Washer

27

203-60-31100

Elbow Assembly

28

203-60-31160

Tube

28

198-60-55510

Breather

29

421-60-35170

Element

30

421-60-35180

Cover

31

421-60-35190

Nut

32

209-60-41113

Tank

33

07040-12412

Plug

34

07002-12434

O-ring
