Запчасти Komatsu PC850-8E0 ЦИЛИНДР РУКОЯТИ, ЛЕВ. (№-) ЦИЛИНДР РУКОЯТИ

Схема запчастей Komatsu PC850-8E0 - ЦИЛИНДР РУКОЯТИ, ЛЕВ. (№-) ЦИЛИНДР РУКОЯТИ
30
29
6
7
7
8
2
13
32
19
14
32
18
31
15
21
26
9
10
11
10
22
23
44
40
16
41
42
25
34
35
37
48
12
27
33
30
29
38
36
47
4
36
39
38
39
4
1
3
45
46
20
5
28
49
24
50
43
17
51
42
41
41
42
51

Артикул

Название

Примечание

Количество

|$0

707-01-0AS40

Cylinder Assembly

1

721-13-18210

Cylinder

2

707-58-12810

Rod

3

707-76-11130

Bushing

4

07145-00110

Seal, Dust, (Kit : K07)

5

07043-00108

Plug, Taper

6

707-76-11130

Bushing

7

07145-00110

Seal, Dust, (Kit : K07)

8

07043-00108

Plug, Taper

9

707-71-32940

Collar

10

707-35-91840

Ring, Back-up, (Kit : K07)

11

07000-15175

O-ring, (Kit : K07)

12

707-71-61330

Plunger

13

707-71-70330

Plunger

14

04260-00952

Ball

15

707-71-91230

Cap

16

707-27-18930

Head, Cylinder

17

707-56-12740

Seal, Dust, (Kit : K07)

18

07179-13136

Ring, Snap

19

707-51-12030

Packing, Rod, (Kit : K07)

20

707-51-12650

Ring, Buffer, (Kit : K07)

21

707-52-90981

Bushing

22

07000-15175

O-ring, (Kit : K07)

23

707-35-91840

Ring, Back-up, (Kit : K07)

24

07179-13126

Ring, Snap

25

01011-82400

Bolt

26

707-88-75410

Washer

27

707-36-18520

Piston

28

707-44-18250

Ring, Piston, (Kit : K07)

29

707-39-18510

Ring, Wear, (Kit : K07)

30

707-44-18920

Ring

31

07000-B5110

O-ring, (Kit : K07)

32

07001-05110

Ring, Back-up, (Kit : K07)

33

01310-01225

Screw

34

707-86-00400

Tube

35

707-88-50890

Bracket

36

707-88-26620

Band

37

707-88-50900

Bracket

38

07372-21250

Bolt

39

01643-51232

Washer

40

07371-51260

Flange, Split

41

01010-81245

Bolt

42

01643-31232

Washer

43

707-88-33040

Cap

44

707-88-33050

Cap

45

07000-13035

O-ring, (Kit : K07)

46

07372-21035

Bolt

47

01643-51032

Washer

48

07372-21060

Bolt

49

01643-51032

Washer

50

07371-31049

Flange, Split

51

707-88-10150

Clamp

Выбрано товаров: 52
