Запчасти Komatsu PC850-8 PPC ЛИНИЯ СОЕД-Е (СОЕД-Е) (B/H)(№-) ГИДРАВЛИКА

1

209-64-16550

JOINT

2

201-60-11390

O-RING

3

20Y-62-19560

O-RING

4

02896-11009

O-RING

5

01010-81230

BOLT

6

175-54-34170

WASHER

7

209-64-16560

JOINT

8

201-60-11390

O-RING

9

20Y-62-19560

O-RING

10

02896-11009

O-RING

11

01010-81230

BOLT

12

01643-31232

WASHER

13

02760-00313

HOSE

14

02760-00314

HOSE

15

20Y-62-22790

BAND, RED

16

20Y-62-22810

BAND, YELLOW

17

20Y-62-22830

BAND, WHITE

18

20Y-62-22860

BAND, BROWN

19

02760-00320

HOSE

20

02760-00328

HOSE

21

02760-00331

HOSE

22

02760-00336

HOSE

23

20Y-62-22790

BAND, RED

24

20Y-62-22820

BAND, BLUE

25

20Y-62-22850

BAND, GREEN

26

02760-00308

HOSE

27

02760-00316

HOSE

28

02760-00317

HOSE

29

02760-00323

HOSE

30

02760-00325

HOSE

31

20Y-62-22820

BAND, BLUE

32

20Y-62-22830

BAND, WHITE

33

20Y-62-22840

BAND, BLACK

34

20Y-62-22850

BAND, GREEN

35

209-64-16822

BRACKET

36

01010-81230

BOLT

37

175-54-34170

WASHER

38

209-64-16920

BRACKET

39

01010-81235

BOLT

40

01643-31232

WASHER

41

20Y-62-15951

CLIP

42

01010-81230

BOLT

43

01643-31232

WASHER

44

21T-06-12650

CLIP

45

01010-81230

BOLT

46

01643-31232

WASHER

47

581-04-22290

CLIP

48

20Y-62-15951

CLIP

49

01010-81230

BOLT

50

01643-31232

WASHER

51

206-06-61130

SWITCH

52

20Y-06-21710

SWITCH
