Запчасти Komatsu PC80MR-3 ПРАВ. ПРИБОРНАЯ ПАНЕЛЬ КОМПОНЕНТЫ ДВИГАТЕЛЯ И ЭЛЕКТРИКА

1

22U-43-R3140

UPPER BOX

2

22U-43-R3111

PLATE

3

01370-00514

SCREW

4

01601-20513

WASHER, SPRING

5

42N-06-13310

PLUG

6

21D-06-12880

PLUG

7

22E-06-21801

POTENTIOMETER

8

37A-09-1W059

SCREW

9

01640-20610

WASHER

10

22U-06-22470

KNOB

11

22U-06-22480

SUPPORT

12

37A-09-1W042

SCREW

13

01640-20508

WASHER

14

08034-20519

CLAMP

15

22U-43-23251

PROTECTION

16

22U-43-23290

CLIP

17

37A-09-1W060

SCREW

18

01640-20610

WASHER

19

37A-09-1W043

SCREW

20

01640-20610

WASHER

21

22U-43-23210

COVER

22

37A-09-1W027

BOLT

23

01640-20408

WASHER

24

2A1-06-11210

SWITCH, WORKING LIGHT

25

22L-09-R3Q10

BULB 30MA 12V

25

22L-09-R3Q30

BULB 1,2W 12V

26

22L-09-R9230

SWITCH, ROTARY BEAM

27

22L-09-R3Q10

BULB 30MA 12V

27

22L-09-R3Q30

BULB 1,2W 12V

28

22E-06-21420

SWITCH, WIPER

29

22L-09-R3Q10

BULB 30MA 12V

29

22L-09-R3Q30

BULB 1,2W 12V

30

22E-06-21440

SWITCH, OVERLOAD

31

22L-09-R3Q10

BULB 30MA 12V

31

22L-09-R3Q30

BULB 1,2W 12V

32

22E-06-21450

SWITCH, HAMMER

33

22L-09-R3Q10

BULB 30MA 12V

33

22L-09-R3Q30

BULB 1,2W 12V
