Запчасти Komatsu PC80MR-3 ГОЛОВКА ЦИЛИНДРОВ И КРЫШКА ДВИГАТЕЛЬ

\0

22E-01-11501

ASPIRATED ENGINE, ASSEMBLY

1

YM129900-07900

LIFTER

2

YM26106-080162

BOLT, FLANGED

3

YM123907-11550

CAP, VALVE

4

YM129927-11700

HEAD ASSEMBLY, CYLINDER

8

YM23876-020000

PLUG, TAPERED

9

YM23876-030000

PLUG, TAPERED

10

YM27241-400000

PLUG

11

YM129907-11100

VALVE, INTAKE

12

YM129907-11110

VALVE, EXHAUST

13

YM129907-11120

SPRING, VALVE

14

YM119620-11180

RETAINER, SPRING

15

YM119803-11340

SEAL, VALVE STEM

16

YM124160-11340

SEAL, VALVE STEM

17

YM129907-11510

BRACKET

19

YM129150-11750

NUT

20

YM123907-11830

SCREW

21

YM123907-11820

STUD

22

YM27310-070001

COTTER

24

YM129907-11800

GUIDE

25

YM119802-11870

PROTECTOR, NOZZLE

26

YM119625-11880

SEAT, NOZZLE

27

YM129907-11910

RETAINER

28

YM129907-11950

BOLT

29

YM24311-000120

O-RING

30

YM119593-11301

BOLT

31

YM129907-11341

SUPPORT

32

YM129907-11250

SHAFT

33

YM129907-11260

SUPPORT

34

YM129907-11270

SUPPORT

35

YM123907-11280

WASHER

36

YM129907-11650

ROCKER SHAFT

38

YM129150-11230

SCREW, VALVE

39

YM129150-11750

NUT

40

YM129907-11660

ROCKER SHAFT

42

YM129150-11230

SCREW, VALVE

43

YM129150-11750

NUT

44

YM129907-11920

RETAINER

45

YM26226-080222

STUD

46

YM26106-080402

BOLT, FLANGED

47

YM26106-080602

BOLT, FLANGED

48

YM26106-080602

BOLT, FLANGED

49

YM26306-080002

NUT, FLANGED

50

YM124160-01751

COVER, FILLER

51

YM129927-11320

BONNET ASSEMBLY

52

YM129907-03011

BAFFLE

53

YM129907-03061

BAFFLE

54

YM129907-03070

BAFFLE

55

YM123907-03100

DIAPHRAGM

56

YM123907-03110

PLATE

57

YM123907-03120

PLATE

58

YM123907-03140

SPRING

60

YM129933-11310

GASKET

61

YM119640-61400

PLUG

62

YM175339-79700

CLIP

63

YM22857-500100

SCREW

64

YM22857-500100

SCREW

65

YM26106-060122

BOLT

66

YM124160-11360

KNOB

67

YM24311-000120

O-RING

68

YM24311-000320

O-RING
