Запчасти Komatsu PC80MR-3 ТОПЛ. НАСОС (/) ДВИГАТЕЛЬ

\0

22E-01-11501

ASPIRATED ENGINE, ASSEMBLY

1

YM729938-51310

INJECTION PUMP, ASSEMBLY

9

KEY

18

STOPPER

19

O-RING

20

O-RING

21

VALVE ASSEMBLY

30

SPRING

31

YM129927-51340

HOLDER

52

PLUG

53

PLUG

54

GASKET

55

PLUG

56

GASKET

57

PIN

58

YM129657-51590

VALVE ASSEMBLY

59

VALVE

62

O-RING

63

RING, BACK-UP

64

O-RING

65

O-RING

66

RING, BACK-UP

67

GASKET

68

SPRING

69

CAP

71

YM119852-51650

SOLENOID VALVE

74

GASKET

95

PISTON

96

SPRING

97

PLUG

98

SEAL, WASHER

99

SEAL, WASHER

100

PLUG

102

O-RING

103

O-RING

105

SEAL, WASHER

106

SPRING WASHER

107

PIN, DOWEL

108

PIN, SPRING

109

O-RING

110

O-RING

111

O-RING

112

BOLT, FLANGED

113

BOLT

116

BOLT

117

NUT

120

JOINT

121

YM129927-51650

WIRING HARNESS

122

CABLE

123

CAP

124

JOINT

125

BRACKET

127

YM158552-52100

PUMP ASSEMBLY, FEED

128

O-RING

129

JOINT

130

SEAL, WASHER

131

SPRING WASHER

132

BOLT

133

NUT

134

PLUG

136

RETAINER

137

BOLT, FLANGED

138

BOLT, FLANGED
