Запчасти Komatsu PC80MR-3 КАБИНА (/9) ЧАСТИ КОРПУСА И КАБИНА

Схема запчастей Komatsu PC80MR-3 - КАБИНА (/9) ЧАСТИ КОРПУСА И КАБИНА
11
10
7
8
9
5
3
51
52
4
6
55
53
54
47
14
50
48
13
56
46
35
12
39
33
2
38
16
57
49
13
16
44
36
14
16
16
15
16
33
12
28
45
34
43
42
16
57
32
33
40
24
29
41
30
25
23
27
21
26
26
22
21
20
22
23
20
25
1
38
31
39
19
56
18
37
17
a
a

Артикул

Название

Примечание

Количество

\0

22E-54-21010

OPERATOR'S CAB, ASSEMBLY

\0

21W-54-R0040

DOOR, ASSEMBLY

\0

21W-54-R1250

DOOR, ASSEMBLY

1

22M-54-14470

HANDLE

2

22M-54-24430

COVER

3

21W-54-R2340

SCREW

4

42N-56-11960

WASHER

5

21W-54-R1260

RUN GUIDE

6

20U-54-44920

SHIM

7

21W-54-R2240

BOLT

8

21W-54-R2440

WASHER

9

20U-54-24923

GUIDE, ASSEMBLY

10

21W-54-R2440

WASHER

11

21W-54-R2230

BOLT

12

20Y-54-14520

LOCK, ASSY.

13

21W-54-R2430

WASHER

14

21W-54-R2220

BOLT

15

22M-54-24330

TIE-ROD

16

205-54-71840

SNAP

17

21W-54-R1290

RUN GUIDE

18

21W-54-R2440

WASHER

19

21W-54-R2240

BOLT

20

20U-54-25321

STRIKER

21

20U-54-25341

SHIM, 1.100 MM

22

21W-54-R2430

WASHER

23

21W-54-R2260

BOLT

24

22B-54-16220

HANDLE

25

21W-54-R2190

SCREW

26

01640-20610

WASHER

27

22M-54-24450

HOUSING

28

21W-54-R2340

SCREW

29

42N-56-11960

WASHER

30

20Y-54-35890

LOCK, ASSEMBLY

31

22B-54-16211

HANDLE

32

22M-54-24370

ROD

33

205-54-71830

SNAP

34

22M-54-24360

TIE-ROD

35

22M-54-24340

TIE-ROD

36

22M-54-24351

ROD

37

21W-54-R3A40

BRACKET

38

21W-54-R2280

BOLT

39

21W-54-R2450

WASHER

40

22M-54-14650

LEVER, ASSY.

41

21W-54-R2250

BOLT

42

01640-20610

WASHER

43

22M-54-14661

LEVER, ASSY.

44

21W-54-R2250

BOLT

45

01640-20610

WASHER

46

21J-54-16630

GRIP

47

21W-54-R2370

SCREW

48

01640-20508

WASHER

49

22M-54-24320

TIE-ROD

50

21W-54-R3A70

BRACKET

51

22M-54-24880

STRIKER

52

22M-54-24870

SHIM

53

22M-54-24490

SHIM

54

21W-54-R2260

BOLT

55

21W-54-R2430

WASHER

56

21W-54-R2490

SHIM

57

08059-00413

CLAMP

Выбрано товаров: 60
