Запчасти Komatsu PC800SE-8R ОСНОВН. НАСОС (/)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$1

708-2K-00113

PUMP ASS'Y

|$3

708-1W-00900

PUMP ASS'Y

|$4

708-1W-00910

PUMP ASS'Y

|$5

708-1W-03870

VALVE ASS'Y

|$6

708-1S-03930

BODY SUB ASS'Y

1

BODY

2

PLUG

3

708-1S-15420

PISTON

4

708-1S-15430

SLEEVE

5

07002-21623

O-RING

6

07000-B1010

O-RING

7

708-1S-15470

SPOOL

8

708-1S-15240

SEAT

9

708-1S-15591

SPRING

10

723-56-31630

PLUG

11

07002-21623

O-RING

12

708-1U-15260

LEVER

13

708-1S-15480

RETAINER

14

708-1S-15280

SPACER

15

708-1S-15490

PLUG

16

01582-11210

NUT

17

07000-11006

O-RING

18

20B-27-11210

BLEEDER

19

07040-11007

PLUG

20

07002-21023

O-RING

21

702-21-57700

PILOT VALVE

22

01252-60635

BOLT

23

07000-13040

O-RING

24

01252-60650

BOLT

25

01252-60635

BOLT

26

04020-00616

PIN,DOWEL

27

07000-B2014

O-RING

28

708-2L-25480

FILTER
