Запчасти Komatsu PC800SE-8E0 ПРОПОРЦИОНАЛЬН. PRESSURE УПРАВЛ-Е (PPC) ТРУБЫ СОЕД-Е, СОЕД-Е (№-) ПРОПОРЦИОНАЛЬН. PRESSURE УПРАВЛ-Е (PPC) ТРУБЫ СОЕД-Е, БЕЗ СТРЕЛА И РУКОЯТЬ ГИДРАВЛ DRIFT PREВЕНТИЛЯТОРION КЛАПАН

1

209-64-16550

Joint

2

201-60-11390

O-ring

3

20Y-62-19560

O-ring

4

02896-11009

O-ring

5

01010-81230

Bolt

6

175-54-34170

Washer

7

209-64-16560

Joint

8

201-60-11390

O-ring

9

20Y-62-19560

O-ring

10

02896-11009

O-ring

11

01010-81230

Bolt

12

01643-31232

Washer

13

02760-00313

Hose, Face Seal Type

14

02760-00314

Hose, Face Seal Type

15

20Y-62-22790

Band, Red

16

20Y-62-22810

Band, Yellow

17

20Y-62-22830

Band, White

18

20Y-62-22860

Band, Brown

19

02760-00320

Hose

20

02760-00328

Hose, Face Seal Type

21

02760-00331

Hose, Face Seal Type

22

02760-00336

Hose, Face Seal Type

23

20Y-62-22790

Band, Red

24

20Y-62-22820

Band, Blue

25

20Y-62-22850

Band, Green

26

02760-00308

Hose, Face Seal Type

27

02760-00316

Hose, Face Seal Type

28

02760-00317

Hose

29

02760-00323

Hose, Face Seal Type

30

02760-00325

Hose

31

20Y-62-22820

Band, Blue

32

20Y-62-22830

Band, White

33

20Y-62-22840

Band, Black

34

20Y-62-22850

Band, Green

35

209-64-16822

Bracket

36

01010-81230

Bolt

37

175-54-34170

Washer

38

209-64-16920

Bracket

39

01010-81235

Bolt

40

01643-31232

Washer

41

20Y-62-15951

Clip

42

04434-53212

Clip

43

01010-81230

Bolt

44

01643-31232

Washer

45

21T-06-12650

Clip

46

01010-81230

Bolt

47

01643-31232

Washer

48

113-899-7950

Clip

49

20Y-62-15951

Clip

50

01010-81230

Bolt

51

01643-31232

Washer

52

01010-81225

Bolt

53

01643-31232

Washer

54

206-06-61130

Switch, Pressure

55

20Y-06-21710

Switch
