Запчасти Komatsu PC800SE-8 ОСНОВН. НАСОС (/)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$1

708-2K-00113

PUMP ASS'Y

|$3

708-1W-00901

PUMP ASS'Y

|$4

708-1W-00911

PUMP ASS'Y

|$5

708-1W-03870

VALVE ASS'Y

|$6

BODY SUB ASS'Y

1

BODY

2

PLUG

3

PISTON

4

SLEEVE

5

07002-21623

O-RING

6

07000-B1010

O-RING

7

SPOOL

8

SEAT

9

SPRING

10

723-56-31630

PLUG

11

07002-21623

O-RING

12

LEVER

13

RETAINER

14

SPACER

15

PLUG

16

01582-11210

NUT

17

O-RING

18

20B-27-11210

BLEEDER

19

07040-11007

PLUG

20

07002-21023

O-RING

21

702-21-57700

PILOT VALVE

22

702-21-55870

O-RING

23

702-21-55880

O-RING

24

702-21-54180

SCREW

25

702-21-55890

O-RING

26

01252-60635

BOLT

27

07000-13040

O-RING

28

01252-60650

BOLT

29

01252-60635

BOLT

30

04020-00616

PIN,DOWEL

31

07000-B2014

O-RING

32

708-2L-25480

FILTER
