Запчасти Komatsu PC800SE-8 ОСНОВН. НАСОС (/)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ
№
Артикул
Название
Примечание
Количество
|$1
708-2K-00113
PUMP ASS'Y
|$3
708-1W-00901
PUMP ASS'Y
|$4
708-1W-00911
PUMP ASS'Y
|$5
708-1W-01916
PUMP SUB ASS'Y
1
708-1W-43310
BLOCK,CYLINDER
2
708-1W-43220
PLATE,VALVE
3
720-68-19610
PIN
4
708-1W-43130
SEAT
5
708-1W-43140
SPRING
6
04065-04818
RING
7
708-1W-43350
GUIDE,RETAINER
8
708-3T-13360
PIN
9
708-1W-43341
RETAINER,SHOE
10
708-1U-13310
PISTON SUB ASS'Y
11
708-1W-44120
PISTON SUB ASS'Y
12
708-3T-14120
SPRING
13
708-1U-14240
SCREW
14
07000-12011
O-RING
15
01643-31232
WASHER
16
01582-11210
NUT
|$1
708-2K-00113
PUMP ASS'Y
|$3
708-1W-00901
PUMP ASS'Y
|$4
708-1W-00911
PUMP ASS'Y
|$5
708-1W-01916
PUMP SUB ASS'Y
1
708-1W-43310
BLOCK,CYLINDER
2
708-1W-43220
PLATE,VALVE
3
720-68-19610
PIN
4
708-1W-43130
SEAT
5
708-1W-43140
SPRING
6
04065-04818
RING
7
708-1W-43350
GUIDE,RETAINER
8
708-3T-13360
PIN
9
708-1W-43341
RETAINER,SHOE
10
708-1U-13310
PISTON SUB ASS'Y
11
708-1W-44120
PISTON SUB ASS'Y
12
708-3T-14120
SPRING
13
708-1U-14240
SCREW
14
07000-12011
O-RING
15
01643-31232
WASHER
16
01582-11210
NUT
Выбрано товаров: 40
