Запчасти Komatsu PC800SE-6 КЛАПАН PPC(ДЛЯ ХОДА)(№-999) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

702-16-01502

PILOT VALVE

|1

702-16-01501

PILOT VALVE

|1

702-16-01500

PILOT VALVE

1

BODY,VALVE

2

PLUG

3

VALVE

4

702-16-51140

SHIM¤ 0.30MM

5

702-16-55870

SPRING

6

702-16-53140

RETAINER

7

702-16-54420

SPRING

8

702-16-53170

PISTON

9

702-16-51270

SEAL

10

07000-12020

O-RING

11

702-16-54170

COLLAR

12

702-16-54311

CASE

|12

702-16-54310

CASE

13

LEVER

14

SHAFT

15

PLATE

|15

PLATE

16

01010-80855

BOLT

17

01643-30823

WASHER

18

01010-80816

BOLT

19

702-16-54331

WASHER¤ 1.60MM

|19

702-16-54341

WASHER¤ 1.30MM

|19

702-16-54351

WASHER¤ 1.00MM

20

04025-00432

PIN,SPRING

21

702-16-54430

BUSHING

22

702-16-54280

SEAL,DUST

23

702-16-54506

DAMPER ASS'Y

|23

702-16-54505

DAMPER ASS'Y

|23

702-16-54503

DAMPER ASS'Y

24

01252-60525

BOLT

25

702-16-54511

PLATE

26

04025-00420

PIN,SPRING

27

LEVER

28

01224-40612

SCREW

29

04022-04016

PIN,DOWEL

30

04022-04010

PIN,DOWEL
