Запчасти Komatsu PC800SE-6 ЦИЛИНДР РУКОЯТИ(№-7) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

209-63-X2351

ARM CYLINDER GROUP,L.H.

G-1

209-63-X2361

ARM CYLINDER GROUP,R.H.

|$3

209-63-02351

CYLINDER ASS'Y

1

209-63-63341

CYLINDER

2

707-76-11130

BUSHING

3

07145-00110

SEAL,DUST (KIT)

4

07043-00108

PLUG

5

707-27-18660

HEAD,CYLINDER

6

707-51-12030

PACKING,ROD (KIT)

7

707-51-12630

RING,BUFFER (KIT)

8

707-52-90950

BUSHING

9

195-63-93170

SEAL,DUST (KIT)

10

07179-13136

RING,SNAP

11

07000-15180

O-RING (KIT)

12

07001-05180

RING,BACK-UP (KIT)

13

07000-15180

O-RING (KIT)

14

07001-05180

RING,BACK-UP (KIT)

15

707-71-31291

COLLAR

16

707-71-31281

COLLAR

17

209-63-56160

RING

18

01011-82400

BOLT

19

707-88-75410

WASHER

20

209-63-63321

ROD,PISTON

21

707-76-11130

BUSHING

22

07145-00110

SEAL,DUST (KIT)

23

07043-00108

PLUG

24

707-36-18500

PISTON

25

07000-12100

O-RING (KIT)

26

707-35-52940

RING,BACK-UP (KIT)

27

707-44-18920

RING

28

707-39-18830

RING,WEAR (KIT)

29

707-44-18280

RING,PISTON (KIT)

30

707-40-18870

SPACER

31

707-71-60300

PLUNGER

32

04260-00952

BALL

33

707-71-91040

SCREW

34

707-71-61300

PLUNGER

35

01252-31455

BOLT

36

209-63-63372

TUBE,L.H.

36

209-63-63472

TUBE,R.H.

37

07000-13035

O-RING (KIT)

38

01010-81060

BOLT

39

01643-51032

WASHER

40

707-88-95800

BAND

41

707-88-95811

BRACKET

42

209-63-63391

BRACKET

42

209-63-63390

BRACKET

43

01010-81240

BOLT

44

01643-31232

WASHER

45

07283-23442

CLIP

46

01599-01011

NUT

47

01643-31032

WASHER

48

07000-13038

O-RING

49

07378-11210

HEAD

50

07371-51260

FLANGE

51

01010-81245

BOLT

52

01643-31232

WASHER

53

07000-13032

O-RING

54

07378-11000

HEAD

55

707-88-84710

PLATE

55

07371-31049

FLANGE

56

01010-81030

BOLT

56

07372-21035

BOLT

57

01643-51032

WASHER

|$66

707-99-68510

SERVICE KIT
