Запчасти Komatsu PC800LC-8R1 УПРАВЛЯЮЩ. КЛАПАН, 4-Х СЕКЦИОНН. (/7) (№7-) УПРАВЛЯЮЩ. КЛАПАН

|$0

709-14-95500

Valve, Control

|$1

709-10-93800

Valve Assembly

1

Valve Body

2

Spool

3

07040-11209

Plug

4

07002-11223

O-ring

5

709-10-91250

Flange

6

709-10-91260

Spring

7

709-10-91240

Flange

8

01010-81030

Bolt

9

01643-31032

Washer

10

07000-12055

O-ring

11

07000-13048

O-ring

12

07000-13040

O-ring

13

709-14-12530

Sleeve

14

709-14-12540

Valve Assembly, Check

15

706-73-70150

Spring

16

709-74-92450

Plug

17

709-74-92460

Nut

18

700-93-11320

O-ring

19

700-93-11330

Ring, Back-up

20

07000-12010

O-ring

21

07001-02010

Ring, Back-up

22

01011-61425

Bolt

23

01011-81215

Bolt

24

01011-81250

Bolt

25

01643-31445

Washer, Flat

26

01643-51232

Washer

27

709-10-91131

Plug

28

07000-13035

O-ring

29

07001-03035

Ring, Back-up

30

07000-13030

O-ring

31

07001-03030

Ring, Back-up

32

709-10-91140

Plate

33

01010-80835

Bolt
