Запчасти Komatsu PC800LC-8R1 СОЕДИНЕНИЕ, КОРПУС (№7-) СОЕДИНЕНИЕ

1

209-01-42111

Case

2

209-01-42121

Shaft

3

209-01-42140

Bearing

4

04070-00140

Ring

5

04071-00250

Ring, Snap, for Hole Side

6

209-01-42151

Plate

7

209-01-42220

Gasket

8

01010-81230

Bolt

9

01643-31232

Washer

10

209-01-42131

Hub

11

01010-81240

Bolt

12

01643-31232

Washer

13

07000-E5500

O-ring

14

01010-81245

Bolt

15

01643-31232

Washer

16

01011-81230

Bolt

17

01643-31232

Washer

18

209-01-42291

Elbow

19

07002-63334

O-ring

20

6138-55-7610

Nipple

21

07286-01025

Hose

22

07285-00130

Clip

23

02782-10317

Elbow

24

02896-21009

O-ring

25

07002-22034

O-ring

26

07030-03034

Breather

27

07005-03016

Seal, Washer

28

02782-10522

Elbow

29

02896-21015

O-ring

30

07002-22434

O-ring

31

02782-10524

Elbow

32

02896-21015

O-ring

33

07002-22434

O-ring

34

07040-12012

Plug

35

07002-22034

O-ring

36

02782-10425

Elbow

37

02896-21012

O-ring

38

07002-22434

O-ring

39

07040-12412

Plug

40

07002-22434

O-ring

41

07049-03038

Plug, Cork
