Запчасти Komatsu PC800LC-8R ГИДР. БАК. (ДЛЯ ЗАПЫЛЕНН. РАЙОНОВ) ГИДРАВЛИКА

1

209-60-77120

COVER

2

07000-15230

O-RING

3

209-60-77330

COVER

4

09455-12013

HINGE (WELDED)

5

209-04-51330

SEAL

6

205-60-71220

LOCK ASS'Y

6

205-54-76280

ROTOR ASS'Y

7

01010-81230

BOLT

8

01643-31232

WASHER

|$14

209-60-77171

STRAINER ASS'Y

9

209-60-77131

ROD ASS'Y

10

12R-60-11230

SPRING

11

20Y-60-21320

HOLDER

12

209-60-51120

STRAINER

13

21N-09-11140

O-RING

14

17A-60-11310

CAP ASS'Y

15

20Y-60-21470

ELEMENT

16

208-60-71180

FILLER NECK

17

20Y-60-21340

GASKET

18

01252-70516

BOLT

19

01601-20513

WASHER

20

07056-10045

STRAINER

21

04065-04718

RING

22

07270-61418

TUBE

23

07285-00155

CLIP

24

04434-51812

CLIP

25

04434-52312

CLIP

26

08017-71902

CONDUIT

27

01010-81225

BOLT

28

01643-31232

WASHER

29

203-60-31100

ELBOW ASS'Y

30

203-60-31160

TUBE

31

198-60-55510

BREATHER,(SEE FIG. Y1890-01A0)

32

209-60-41112

TANK

33

07040-12412

PLUG

34

07002-12434

O-RING
