Запчасти Komatsu PC800LC-8R КЛАПАН PPC(ДЛЯ РАБОЧ. ОБОРУД-Я) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$2

702-16-06151

PILOT VALVE

|$3

702-16-06150

PILOT VALVE

1

BODY,VALVE

2

VALVE

3

SPRING

4

PISTON

5

702-16-51140

SHIM, 0.30MM

6

702-16-75720

SPRING

7

702-16-53140

RETAINER

8

702-16-75750

SPRING

9

702-16-75760

SPRING

10

702-16-53170

PISTON

11

702-16-71210

SEAL

11

702-16-71150

SEAL

12

702-16-71160

SEAT

13

702-16-71280

BOOT

14

702-16-71131

PLATE

15

702-16-71141

PLATE

16

01010-80620

BOLT

17

702-16-51240

JOINT,UNIVERSAL

18

DISC

19

702-16-71441

NUT

20

702-16-53761

COVER

21

720-68-15240

FILTER

22

07000-B2021

O-RING

22

07000-12021

O-RING

23

702-16-57260

O-RING

23

702-16-53910

O-RING

24

702-16-57270

O-RING

24

702-16-53920

O-RING

25

01252-60835

BOLT
