Запчасти Komatsu PC800LC-8K ПОВОРОТНОЕ СОЕДИНЕНИЕ Y ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

703-11-00111

SWIVEL JOINT ASSEMBLY,(FINAL COATING)

|1

703-11-00110

SWIVEL JOINT ASSEMBLY,(FINAL COATING)

1

703-11-91131

ROTOR

|1

703-11-91130

ROTOR

2

703-11-95120

SEAL

3

703-11-96120

SEAL,OIL

4

04071-00140

RING,SNAP

5

703-11-92132

SHAFT

|5

703-11-92131

SHAFT

6

703-11-98210

PLUG

7

07002-13034

O-RING

8

703-11-94120

PLATE

9

04064-01030

RING,SNAP

10

703-11-93131

COVER

11

07000-02140

O-RING

12

01010-81040

BOLT

|12

01010-51040

BOLT

13

01643-31032

WASHER,SPRING

|13

01602-21030

WASHER,SPRING
