Запчасти Komatsu PC800LC-8K ЛЕВ. ДВЕРЬ (КАБИНА) M ЧАСТИ КОРПУСА

1

209-54-45711

FRAME

|1

209-54-42212

FRAME

2

20Y-54-28170

BRACKET

3

01010-81230

BOLT

4

01643-31232

WASHER

5

205-54-51970

DOVE TAIL

6

01010-80616

BOLT

7

01643-30623

WASHER

8

209-54-74490

BRACKET

9

01010-81230

BOLT

10

01643-31232

WASHER

11

209-54-63260

BRACKET

12

01010-81230

BOLT

13

01643-31232

WASHER

14

20Y-54-11611

STOPPER

15

01580-11008

NUT

16

209-54-45231

COVER

|16

209-54-42230

COVER

17

198-54-41982

LOCK ASSEMBLY (WELDED)

18

203-54-32260

STOPPER

19

209-54-42290

SHEET

20

209-54-42510

SHEET

21

20Y-54-28161

HINGE (WELDED)

22

01010-81230

BOLT

23

01643-31232

WASHER

24

205-54-53550

DOVE TAIL

25

01010-80616

BOLT

26

01643-30623

WASHER

27

20Y-54-29232

BAR

28

20B-54-12210

SPRING

29

01023-10408

SCREW

30

209-54-45221

COVER

|30

209-54-42221

COVER

31

198-54-41982

LOCK ASSEMBLY (WELDED)

32

209-54-42251

SHEET

33

209-54-42261

SHEET

34

209-54-42271

SHEET

35

209-54-42281

SHEET

36

209-54-74681

SHEET

37

20Y-54-28161

HINGE (WELDED)

38

01010-81230

BOLT

39

01643-31232

WASHER

40

205-54-53550

DOVE TAIL

41

01010-80616

BOLT

42

01643-30623

WASHER

43

20Y-54-29232

BAR

44

20B-54-12210

SPRING

45

01023-10408

SCREW

46

01010-81230

BOLT

47

01643-31232

WASHER

48

07049-01215

PLUG

49

01010-81230

BOLT

|49

01010-81230

BOLT

50

01643-31232

WASHER

|50

01643-31232

WASHER

51

01010-81230

BOLT

52

175-54-34170

WASHER
