Запчасти Komatsu PC800LC-8E0 СТРЕЛА, 8MM, (CLV), ЦИЛИНДР РУКОЯТИТРУБЫ (/7) СТРЕЛА, 8MM, (CLV), ЦИЛИНДР РУКОЯТИТРУБЫ

1

209-64-17240

Nipple

2

02896-11009

O-Ring

|$3

209-64-17350

Hose Assembly

3

20Y-62-22790

Band, Red

4

20Y-62-22820

Band, Blue

5

02760-00360

Hose

6

02760-00361

Hose

7

207-62-52430

Clamp

8

205-62-73430

Seat

9

04435-51712

Clip

10

01010-81230

Bolt

11

01643-31232

Washer

12

01580-11210

Nut

13

207-62-52430

Clamp

14

205-62-73430

Seat

15

209-64-17380

Tee

16

02896-11009

O-Ring

17

175-40-22540

Spacer

18

01010-81285

Bolt

19

01643-31232

Washer

20

01010-81230

Bolt

21

01643-31232

Washer

22

01580-11210

Nut

23

207-62-52430

Clamp

24

205-62-73430

Seat

25

209-64-17380

Tee

26

02896-11009

O-Ring

27

195-33-11220

Spacer

28

01010-81260

Bolt

29

01643-31232

Washer

30

01010-81230

Bolt

31

01643-31232

Washer

32

01580-11210

Nut

|$34

209-64-17360

Hose Assembly

33

20Y-62-22820

Band, Blue

34

02760-003A5

Hose

35

02760-003A7

Hose

|$38

209-64-17370

Hose Assembly

36

20Y-62-22820

Band, Blue

37

02760-003A3

Hose

38

02760-003A5

Hose

39

02756-203A5

Hose
