Запчасти Komatsu PC800LC-8E0 ПРОПОРЦИОНАЛЬН. PRESSURE УПРАВЛ-Е (PPC) ТРУБЫ СОЕД-Е, НАВЕСН. ОБОРУД, СОЕД-Е ПРОПОРЦИОНАЛЬН. PRESSURE УПРАВЛ-Е (PPC) ТРУБЫ СОЕД-Е, НАВЕСН. ОБОРУД, СТРЕЛА И РУКОЯТЬ

1

209-64-17470

Joint

2

201-60-11390

O-Ring

3

20Y-62-19560

O-Ring

4

201-60-11390

O-Ring

5

20Y-62-19560

O-Ring

6

02896-11009

O-Ring

7

01010-81230

Bolt

8

175-54-34170

Washer

9

209-64-16560

Joint

10

201-60-11390

O-Ring

11

20Y-62-19560

O-Ring

12

02896-11009

O-Ring

13

01010-81230

Bolt

14

01643-31232

Washer

|$15

209-64-45440

Hose Assembly

15

02760-00313

Hose, Face Seal Type

16

02760-00314

Hose, Face Seal Type

17

20Y-62-22810

Band, Yellow

18

20Y-62-22860

Band, Brown

|$20

209-62-46260

Hose Assembly

19

02760-00323

Hose, Face Seal Type

20

02760-00328

Hose, Face Seal Type

21

02760-00331

Hose, Face Seal Type

22

02760-00336

Hose, Face Seal Type

23

20Y-62-22790

Band, Red

24

20Y-62-22820

Band, Blue

25

20Y-62-22850

Band, Green

|$28

209-64-45650

Hose Assembly

26

02760-00316

Hose, Face Seal Type

27

02760-00317

Hose

28

02760-00323

Hose, Face Seal Type

29

02760-00325

Hose

30

20Y-62-22820

Band, Blue

31

20Y-62-22830

Band, White

32

20Y-62-22840

Band, Black

33

20Y-62-22850

Band, Green

|$37

209-62-48880

Hose Assembly

34

02760-00324

Hose, Face Seal Type

35

02760-00326

Hose, Face Seal Type

36

02760-00335

Hose, Face Seal Type

37

02760-00340

Hose, Face Seal Type

38

20Y-62-22790

Band, Red

39

20Y-62-22810

Band, Yellow

40

20Y-62-22830

Band, White

41

20Y-62-22860

Band, Brown
