Запчасти Komatsu PC800LC-8E0 КАБИНА, ПЕРЕДН. ОКНА (№8-) КАБИНА, EOPS КАБИНА, ЗАЩИТА ОТ ВАНДАЛИЗМА, С СИДЕНЬЕ ОПЕРАТОРА, ПОДОГРЕВED, KOMTRAX

|$0

209-53-00254

Cab Assembly

|$1

20Y-53-00031

Window Assembly

1

20Y-53-11511

Frame

2

20Y-53-11520

Glass

3

20Y-54-51531

Seal

4

20Y-53-11551

Seal

5

22B-54-15411

Lock Assembly

6

22B-54-15440

Case

7

22B-54-15470

Knob

8

22B-54-15421

Lock Assembly

9

22B-54-15450

Case

10

22B-54-15480

Knob

11

01010-D0816

Bolt

12

418-54-35450

Washer

13

20Y-54-52621

Roller

14

20Y-54-52681

Roller

15

20Y-53-12330

Pin

16

20Y-54-14590

Handle

17

01245-00616

Screw

18

01643-70623

Washer

19

20Y-53-12830

Bracket

20

01245-00816

Screw

21

01643-70823

Washer

22

20Y-54-51670

Stopper

23

20Y-54-51680

Stopper

24

01252-80616

Bolt

25

01643-70623

Washer

26

20Y-53-11561

Block Assembly

27

01245-00816

Screw

28

01643-70823

Washer

29

20Y-53-11661

Bracket

30

01245-00816

Screw

31

01643-70823

Washer

32

21J-06-12440

Switch

33

01583-11811

Nut

34

20Y-53-11581

Bracket

35

20Y-53-11641

Bracket

36

01435-00612

Bolt

37

20Y-54-11611

Stopper

38

01580-11008

Nut

39

20Y-54-51621

Striker

40

01584-31008

Nut

41

01643-71032

Washer

42

20Y-53-11540

Seal

43

20Y-54-51420

Seal

44

20Y-53-12531

Cover

45

20Y-53-12310

Collar

46

01245-00616

Screw

47

01643-70623

Washer
