Запчасти Komatsu PC800LC-8 REMOVER ЦИЛИНДР (ДЛЯ ПРОТИВОВЕС NO.) (ЛЕВ.) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

707-01-XP310

CYLINDER GROUP,L.H. (FINAL COATING)

|$3

707-01-0K360

CYLINDER ASS'Y

1

721-11-12980

CYLINDER

2

707-76-70651

BUSHING

3

07145-00070

SEAL,DUST (KIT)

4

707-58-85460

ROD,PISTON

5

707-76-80431

BUSHING

6

07145-00080

SEAL,DUST (KIT)

7

707-27-12921

HEAD,CYLINDER

8

07179-13099

RING,SNAP

9

707-56-85510

SEAL,DUST (KIT)

10

707-52-90610

BUSHING

11

707-51-85030

PACKING,ROD (KIT)

12

07000-15110

O-RING (KIT)

13

707-35-91220

RING,BACK-UP (KIT)

14

707-51-85640

RING,BUFFER (KIT)

15

01010-81670

BOLT

16

01643-51645

WASHER

17

707-36-12851

PISTON

18

707-44-12180

RING,PISTON (KIT)

19

707-39-12140

RING,WEAR (KIT)

20

707-44-12911

RING

21

07000-15075

O-RING (KIT)

22

707-35-90930

RING,BACK-UP (KIT)

23

01310-01216

SCREW

24

07020-00675

FITTING,GREASE

25

07020-00000

FITTING,GREASE

26

707-86-68120

TUBE,L.H.

27

707-86-67990

TUBE

28

07372-21060

BOLT

29

01643-51032

WASHER

30

07372-21045

BOLT

31

01643-51032

WASHER

32

07000-13030

O-RING (KIT)

33

707-88-28510

BRACKET

34

707-88-28490

BRACKET

35

07372-21035

BOLT

36

01643-51032

WASHER

37

707-88-27770

BRACKET

38

01010-81050

BOLT

39

01643-31032

WASHER

40

07283-32738

CLIP

41

01597-01009

NUT

42

01643-31032

WASHER

|$47

707-99-46030

SERVICE KIT
