Запчасти Komatsu PC800LC-8 ЦИЛИНДР РУКОЯТИ(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

707-01-XP281

CYLINDER GROUP,(FINAL COATING)

|$3

707-01-0CC50

CYLINDER ASS'Y

1

707-13-20460

CYLINDER

2

707-46-13010

BUSHING

3

07043-00108

PLUG

4

707-27-20910

HEAD,CYLINDER

5

707-51-14080

PACKING,ROD (KIT)

6

707-51-14650

RING,BUFFER (KIT)

7

707-52-91171

BUSHING

8

707-75-14110

RING,SNAP

9

707-56-14740

SEAL,DUST (KIT)

10

07179-14160

RING,SNAP

11

07000-15195

O-RING (KIT)

12

07001-05195

RING,BACK-UP (KIT)

13

07000-15195

O-RING (KIT)

14

07001-05195

RING,BACK-UP (KIT)

15

721-71-32020

COLLAR

16

01011-82705

BOLT

17

01643-32780

WASHER

18

209-63-64320

ROD,PISTON

19

707-46-11520

BUSHING

20

07043-00108

PLUG

21

707-36-20450

PISTON

22

07000-B5130

O-RING (KIT)

23

07001-05130

RING,BACK-UP (KIT)

24

707-44-20910

RING

25

707-39-20020

RING,WEAR (KIT)

26

707-44-20150

RING,PISTON (KIT)

27

707-71-70330

PLUNGER

28

04260-00952

BALL

29

707-71-91230

CAP

30

707-71-61510

PLUNGER

31

01310-01232

SCREW

32

707-86-14220

TUBE

33

07000-13038

O-RING (KIT)

34

01010-81280

BOLT

35

01643-31232

WASHER

36

707-88-50910

BRACKET

37

707-88-26610

BAND

38

07372-21250

BOLT

39

01643-51232

WASHER

40

176-61-41330

CLAMP

41

01010-81250

BOLT

42

01643-31232

WASHER

43

707-88-33060

CAP

44

07371-51470

FLANGE

45

01010-81455

BOLT

46

01643-31445

WASHER

|$51

707-99-76240

SERVICE KIT
