Запчасти Komatsu PC800-8R НИЖН. ГИДРОЦИЛИНДР КОВША (ДЛЯ ПОГРУЗ.) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

707-01-XY920

CYLINDER GROUP,BOTTOM DUMP, L.H.

G-2

707-01-XY930

CYLINDER GROUP,BOTTOM DUMP, R.H.

|$5

707-01-0C500

CYLINDER ASS'Y,BOTTOM DUMP

1

707-13-14650

CYLINDER

2

207-63-76170

BUSHING

3

07145-00090

SEAL,DUST (KIT)

4

07043-00108

PLUG,GREASE

5

707-27-14830

HEAD,CYLINDER

6

195-63-94170

SEAL,DUST (KIT)

7

07179-13104

RING,SNAP

8

707-52-90680

BUSHING

9

707-51-90030

PACKING,ROD (KIT)

10

707-51-90640

RING,BUFFER (KIT)

11

07000-15130

O-RING (KIT)

12

707-35-91420

RING,BACK-UP (KIT)

13

01010-81875

BOLT

14

707-41-11840

WASHER

15

707-58-90980

ROD,PISTON

16

707-76-90040

BUSHING

17

07145-00090

SEAL,DUST (KIT)

18

07043-00108

PLUG,GREASE

19

707-36-14370

PISTON

20

01310-01216

SCREW

21

707-44-14180

RING,PISTON (KIT)

22

707-39-14820

RING,WEAR (KIT)

23

707-44-14910

RING

24

07000-15080

O-RING (KIT)

25

707-35-90940

RING,BACK-UP (KIT)

26

707-86-11880

BLOCK,L.H.

26

707-86-11890

BLOCK,R.H.

27

209-62-53620

TUBE,L.H.

27

209-62-53630

TUBE,R.H.

28

07000-13035

O-RING (KIT)

29

01435-01080

BOLT

30

01435-01060

BOLT

31

209-62-53670

BRACKET

32

209-62-53660

BAND

33

01435-01035

BOLT

34

07282-03411

CLAMP

35

01435-01020

BOLT

36

707-88-33040

CAP

37

07371-31049

FLANGE

38

07372-21035

BOLT

39

01643-51032

WASHER

|$48

707-99-56220

SERVICE KIT
