Запчасти Komatsu PC800-8R ОХЛАЖД-Е (SUB-БАК) СИСТЕМА ОХЛАЖДЕНИЯ

1

209-03-41821

HOSE

2

07285-00110

CLIP

3

198-03-79210

JOINT

4

01010-81230

BOLT

5

01643-31232

WASHER

6

209-03-77430

HOSE, 450MM

7

07285-00110

CLIP

8

209-03-77440

HOSE, 300MM

9

07285-00110

CLIP

10

04434-51212

CLIP

11

01010-81220

BOLT

12

01643-31232

WASHER

13

21N-03-31491

TANK

13

21N-03-31490

TANK

14

21N-03-32360

CAP ASS'Y

15

21N-03-32351

CAP ASS'Y

15

21N-03-32350

CAP ASS'Y

|$24

ND071370-0190

SWITCH

16

08055-00282

CONNECTOR

17

203-03-41260

HOSE

18

07285-00110

CLIP

19

209-03-77420

HOSE, 2200MM

20

07285-00110

CLIP

21

04434-51212

CLIP

22

01010-81220

BOLT

23

01643-31232

WASHER

24

04435-51212

CLIP

25

01010-81220

BOLT

26

01643-31232

WASHER

27

209-03-77340

BAND

28

01010-80820

BOLT

29

01643-30823

WASHER

30

209-03-77352

BRACKET

31

205-03-71440

SHEET

32

01010-81230

BOLT

33

01643-31232

WASHER

34

209-03-41991

BRACKET

35

01010-81230

BOLT

36

01643-31232

WASHER
